Now available EC17C43 for Mercedes Class A W169 and Class B W245:

• read/write EEPROM in boot mode via MDP Evo EDC17Prog interface
• checksum online recalculation

Now available Bosch number description, you get:

• ECU's description
• compatible ECUs

Now available Insignia EDC17 and Giulietta MED17:

• read/write EEPROM in boot mode via MDP Evo EDC17Prog interface
• online checksum recalculation

Dialprog features are now available for MRPPad also

Now available EDC16C3 for Renault:

•     read/write characteristic parameters

plus, IAW4AF HW 204:

•     read/write EEPROM 95160
•     read/write Flash ST10F168

Now available EDC17C49 - EDC17C79 - MED17.3.1 ECUs for Fiat group:

•     read/write EEPROM in boot mode via MDP Evo EDC17Prog interface
•   online checksum recalculation

plus, for EDC15C5 Euro 2 Fiat Group:

•     read/write EEPROM

Now available Renault Trafic EDC16C36 and Nissan Qashqai EDC16CP33:


•   read/write characteristic parameters Renault Trafic EDC16C36 via OBDII
•   read/write characteristic parameters Nissan Qashqai EDC16CP33 via OBDII

Now available:

• read/write EEPROM for Mini MEV17 in boot mode via EDC17Prog interface plus online checksum recalculation
• read/write flash for IAW5NF Motorola 68F375

Now available key coding for Renault Laguna 2 and Clio 2, 3 - Smart Card and UCH unit:

•     read/write EEPROM 93C66 via OBDII



Now available IAW5N Fiat Group via OBDII:

•     read/write EEPROM

plus, Open Denso 1.7CTDI < 2010 CAN e 1.7CTDI > 2010 CAN

•     read/write characteristic parameters

Now available EDC15C6 - EDC15C7 ECUs for Fiat group via OBDII:

• read/write EEPROM
• read/write characteristic parameters
• read code badge



Now available Opel group Denso ECUs via OBDII:
    Read/write EEPROM and flash via OBDII for ECUs with 93C86 in versions:

•    1 93C66 memory and 64F7055 micro
•    3 93C86 memory and 64F7058 micro
•    4 93C86 memory and 64F7059 micro



Now available Bosch ME3.1, ME7.3.1, ME7.3H4 ECUs via OBDII:

• read/write EEPROM 95080
• read/write characteristic parameters

Now available EDC16 and DCM 1.2 for Renault group:

• Rread/write characteristic parameters of Bosch EDC16CP33 UDS e Delphi DCM1.2 via OBDII

Now available EDC15 of gruppo VAG:

• read/write ERPROM
• IMMO data decode
• read/write characteristic parameters




Now available EDC16 for VAG group:

•   read/write characteristic parameters of EDC16U1, EDC16U31, EDC16U34, EDC16CP31, EDC16CP34
•   decode IMMO data



Now available EDC17 of Renault:

•     read/write characteristic parameters via OBDII of EDC17C11, EDC17C42

Now available for IAW9GF of Fiat group via OBDII:

•     read/write EEPROM and flash via OBDII



Now available for 4AF/59F/5AF/5NF of Fiat group:

•     read/write EEPROM and flash

Now available VAG Group EDC17 read/write of EEPROM in boot mode by means of EDC17Prog interface for

•     Bosch EDC17CP04, EDC17CP14, EDC17CP20, EDC17C46
•     Siemens PCR2.1

Now available for strumentazione del gruppo Fiat

• Read/write characteristic parameters
• Service executing adjustment
• Read/write EEPROM (not supported for all devices)



It's now available key coding via OBDII for Smart Card Renault for

• Megane II
• Scenic II



• Bosch ME5.2 - ME7.2 - ME7.8
• Siemens SDI3 - SDI4



Bosch EDC17 - MED17 - MEV17 Checksum recalculation for EEPROM is now available

Siemens tricore Checksum recalculation for EEPROM is now available

Automotive Art presents MRP on Android

Everything starts with an idea ...

take a Samsung 10-inch tablet, install MRP, realize a high-performace multiplexer OBD plug and combine everything into a single product

MRPPad borns

MRP stands for "Multi Repair Professional". MRP is a software designed for the electronic automotive industry operators to solve numerous problems related to engine control units, body coomputers, clusters, microcontrollers, etc.

Main fuctions:

1. reuse already encoded units
2. reset all parameters ("virgin state")
3. readjust all parameters to your own vehicle
4. special functions
5. read CODE badge
6. recalculate checksum
7. erase injectors coding (only for fasoline ECU)

Fiat - Alfa - Lancia

Fiat Professional

Renault

PSA Group

Opel

Porsche - Ford (coming soon)

Bosch EDC16C39 DPF EU4
Bosch EDC16C39 DPF EU5
Fiat 16 EU4, Fiat 16 EU5
MultiJet MJD6-6JF -> OBD
MultiJet MJD6-6F3 -> OBD
MultiJet MJD6-8DF -> OBD
MultiJet MJ8D-8F2/8F3 -> OBD
MultiAir IAW8GM -> OBD
TwinAir IAW8GS -> OBD

Bosch EDC16CP33 CAN DPF
Bosch EDC16CP33 CAN NO DPF
Bosch EDC17C42
Siemens SID

Magneti Marelli MJD6.6JO
Magneti MarelliMJD6.6O2
Magneti Marelli MJD6.6O3

Samsung Galaxy Tab  A 10.1

Dimensions 254.2 x 155.3 x 8.2 mm (10.01 x 6.11 x 0.32 in)
Size 10.1 inches (~74.9% screen-to-body ratio)
OS Android OS, v6.0 (Marshmallow)
CPU Octa-core (4x1.6 GHz Cortex-A53 & 4x1.0 GHz Cortex-A53)
GPU Mali-T830 MP2
Card slot microSD, up to 256 GB (dedicated slot)
Internal 16 GB, 2 GB RAM or 32 GB, 3 GB RAM (S-Pen version)

Samsung Galaxy Tab  29.7

Dimensions 237.3 x 169 x 5.6 mm (9.34 x 6.65 x 0.22 in)
Size 9.7 inches (~72.7% screen-to-body ratio)
OS Android OS, v5.0.2 (Lollipop), upgradable to v6.0.1 (Marshmallow) - T810, T815
Android OS, v6.0.1 (Marshmallow), upgradable to v7.0 (Nougat) - T813N, T819N
CPU Octa-core (4x1.9 GHz & 4x1.3 GHz) - T810, T815
Octa-core (4x1.8 GHz Cortex-A72 & 4x1.4 GHz Cortex-A53) - T813N, T819N
GPU Mali-T760 MP6 - T810, T815
Adreno 510 - T813N, T819N
Card slot microSD, up to 256 GB (dedicated slot)
Internal 32/64 GB, 3 GB RAM

CPU: 32-bit 120MHz RAM-64KB Flash-512KB/ RAM: 8MB - Flash: 512MB/ Supported communication protocols: CAN, K-line/ MultiPlexer System/ Connectivity: mini USB, 232 serial, Bluetooth 3.0
